360010
The XRAY XB4C 2022 Carpet Edition 1/10 4WD Electric Buggy Kit is the next level in luxury 4WD chassis. Updates and revision have been made to further optimize the chassis from previous XB4 models. XRAY has held their high standards and deliver a highly competitive RC car for the most demanding racers, developed with attention to the finest detail, and backed by premium service & support.
The most notable improvement to the XB4 chassis is the revised chassis for more forward weight. By moving the weight more forward, XRAY has greatly increased the stability throughout the chassis. This increase in forward weight also makes aggressive landings more forgiving. The side guards complement the chassis by generating symmetrical flex. The carpet edition features a one-way slipper clutch that gives the user far more control over power delivery. The front of the slipper allows for 40-50% slippage when off throttle and will lock up on-power. These advancements aid in landing, high-speed braking and will help prevent traction roll at corner entry.
NOTE: Completed kit shown in photos is for illustrative purposes only. The model you will receive is a kit that requires assembly and accessories. See needed to complete list below for a full list of items required to complete the model.
2022 XB4 Features:
- Revised chassis for more forward weight
- Multiple holes for battery position adjustment
- Updated side guard mounting for symmetrical flex
- Shorter chassis with better machining for motor clearance
- Center slipper has been moved forward in the chassis for added stability - landing
- Surface specific chassis braces for precise chassis control
- Center dogbone driveshafts for reduced maintenance
- Updated servo mount with graphite stiffener
- Suspension arms are updated to increase stability and traction
- An electronic plate allows quick removal from the chassis
- Front and rear bulkhead allows for quick access to the differentials
- Adjustable differential height adjustments for precise tuning
- Front and rear differentials hold 10% more fluid for increased consistency
- Motor mount allows for easy access to the pinion gear
- Shock towers have also been redesigned to allow for precise setup adjustments
- Rear suspension holders can be installed in upward or downward orientations for added roll center adjustments
Carpet Edition Features:
- Multi-Adjustable slipper one-way clutch
- Rear wheel hubs (3-slots)
- Front wheel hubs (2-slots)
- Anti-roll bars (1.8mm/1.8mm)
- Graphite chassis T-brace (Front)
- Central dogbone driveshaft (47mm)
- Aluminum center bulkhead
- Gamma 4C Body
- Angle Hub (1-dot)
- 700/550CST shock oils
Includes:
Needed to Complete:
- (1) 2+ Channel Transmitter with Receiver
- (1) Electronic Speed Controller (ESC)
- (1) Steering Servo
- (1) 540 Motor
- (1) Pinion Gear
- (1) LiPo Battery
- (1) Compatible Charger
- Polycarbonate Paint for Body
- (4) Tires and Wheels
